- Innovation and Challenges
Pulley
Manufacturing Process
- 01Urethane casting
- 02CNC Processing
- 03Inspection for Shipping out
SPEC
| MODLE NAME | SIZE | APPLICATION | P/U MATERIAL |
|---|---|---|---|
| HCT PULLEY | Small / Large | MAIN ROLLER WIRE GUIDE ROLLER | SU4500 |
| M/B PULLEY | Small / Large | MAIN ROLLER WIRE GUIDE ROLLER | SU9500 |
| TOYO PULLEY | Small / Large | MAIN ROLLER WIRE GUIDE ROLLER | SU9500 |
| NTC PULLEY | 442DM, 444A, 454B, PV500, PV1000 |
MAIN ROLLER WIRE GUIDE ROLLER | SU6300, SU9500 |
| TAKATORI PULLEY | ∮104, ∮76, ∮64, ∮54 | WORK ROLLER WIRE GUIDE ROLLER | SU9500 |
※ Serving as WIRE GUIDE OF MAIN ROLLER at the time of cutting SILICON WAFER
Touch Roller & Guide Roller
- HCT Touch Roller
- NTC Touch Roller
- TOYO Touch Roller
- NTC Guide Roller
SPEC
| MODLE NAME | SIZE | APPLICATION | MATERIAL |
|---|---|---|---|
| HCT TOUCH ROLLER | 69.5 X 59.3 X 339 | MAIN ROLLER WIRE GUIDE ROLLER | URETHANE |
| NTC TOUCH ROLLER | 50 X 30 X 40 | MAIN ROLLER WIRE GUIDE ROLLER | URETHANE |
| TOYO TOUCH ROLLER | 100 X 89.7 X 290 | MAIN ROLLER WIRE GUIDE ROLLER | URETHANE |
| NTC GUIDE ROLLER | 86 X 50 X 25 | MAIN ROLLER WIRE GUIDE ROLLER | URETHANE |
※ Serving as WIRE GUIDE OF MAIN ROLLER at the time of cutting SILICON WAFER
Pulley Roller
- HCT Pulley (Small)
- HCT Pulley (Large)
- M/B Pulley (Small)
- M/B Pulley (Large)
- TOYO Pulley (Small)
- TOYO Pulley (Large)
- Sapphire Takatori Pulley (∮104)
- Sapphire Takatori Pulley (∮76)
- HCT Pulley (Small)
- Sapphire Takatori Pulley (∮54)
- Sapphire TOYO Pulley(∮134)
- PV500 Pulley(∮114)
